LA39-E（Φ16mm）
Aesthetic, delicate, compact, quick-mount and reliable. Round, square and rectangular heads.
-
Rated Insulation Voltage
AC250V 50Hz
-
Rated Thermal Current
5A
-
Electrical Endurance
100,000 times for AC-15 50,000 times for DC-13
-
Rated Current
AC-15 24V/2A、110V/1A、220V/0.5A
DC-13 24V/0.7A、110V/0.2A、220V/0.1A
Product Features
Technical Parameters
Main Parameters
|
Rated Insulation Voltage |
AC250V 50Hz |
|
Power Frequency Withstand Voltage |
AC1500V 50Hz .5s |
|
Mechanical Endurance |
1,000,000 times for normal pushbuttons,100,000 times for knobs,50,000 times for key switches and E-stop pushbuttons |
|
Electrical Endurance |
100,000 times for AC-15 50,000 times for DC-13 |
|
Ambient Temperature |
-25℃～55℃ |
|
Storage Temperature |
-30℃～70℃ |
|
Action Frequency |
1,200 times per hour |
|
Certificate |
CCC、CE、RoHS |
|
Compliance Standards |
IEC 60947 / GB 14048.5 |
|
Degree of Protection |
IP40 |
|
Altitude |
Not more than 2,000m |
|
Rated Thermal Current |
5A |
