LA39-J（Φ22mm）

Compact pushbuttons are the products independently researched and developed by our company. Aesthetic, delicate, compact and reliable.

Important Parameters

Compact structure, with head integrated with contact, Mounting cut-outs: φ22.5mm;

Contact combination type: One ON and One OFF, Two NO, Two NC, being economic and practical;

The symbol leaf or label frame can be provided according to the requirements of the operation instructions from the customers.

Rated Insulation Voltage	AC300V
Power Frequency Withstand Voltage	AC1890V 50Hz .5s
Mechanical Endurance	1,000,000 times for normal pushbuttons
Electrical Endurance	100,000 times
Ambient Temperature	-25℃～55℃
Storage Temperature	-30℃～70℃
Action Frequency	1,200 times per hour
Certificate	CCC、CE、RoHS
Compliance Standards	IEC 60947 / GB 14048.5
Degree of Protection	IP40; IP67 with F1 protective cover installed
Altitude	Not more than 2,000m
Rated Thermal Current	5A
