ALH-0.66 III-P
Novel design, advanced compensation method, excellent process technology, safe and reliable performance, small and aesthetic appearance, as well as complete varieties, ideal for control, protection, and measurement.
-
Rated Insulation Voltage
AC660V
-
Power frequency withstand voltage
3kV (1min, 50Hz; between the enclosure and secondary terminal)
-
Highest Degree Of Protection
5P20
-
Maximum Primary Side Current
6300A
Product Features
Technical Parameters
Main Parameters
|
Rated Operating Voltage (Un) |
AC660V |
|
Rated Frequency |
50/60Hz |
|
Insulation Class |
E |
|
Altitude |
≤1,000m (for regular applications: for special applications at altitudes >1,000m, the appropriate transformers must be selected according to the constraints specified in GB20840) |
|
Compliance Standards |
GB20840 |
|
Primary Current |
200A-6300A |
|
Secondary Current |
5A/1A |
|
Ambient Temperature for Use |
-25℃~+40℃ |
|
Maximum Temperature Resistance |
120℃ |
|
Ambient Temperature for Storage |
-40℃~+70℃ |
|
Accuracy Grade |
5P5、5P10、5P15、5P20、10P5、10P10、10P15、10P20 |
